Fast guide to
Smarty's SSR software levels
No need for a PC. No need to
know about binary code. No need to spend countless hours
on a complicated software.
No need to become a software engineer to fine tune your
The SSR delivers the right combination of performance
parameters to fully customize your engine. No matter what
modifications you have done to it!
Whatever race and class you want to compete in, the SSR
has the answer!
How it works?
The SSR provides just one base performance software that
takes care of all the limiting factors like the speed /
RPM / Torque & boost limiters. Then you will need to
fine tune theinjection duration, injection timing &
rail pressure to the truck's needs. The three most
critical performance parameters in a Diesel engine!In
order to allow the complete customization of the
performance software to the particular engine's needs, the
SSR provides 50 levels each for the following parameters:
- Low Load injection Timing ( LLT )
- High Load injection Timing ( HLT )
- Low Load injection Duration ( LLD )
- High Load injection duration ( HLD )
- Low Load Rail Pressure ( LLRP )
- High Load Rail Pressure ( HLRP )
All you need to do is to
select the tuning parameters that match your truck best,
Power on Demand
100 power levels selectable in just one second during the
It's easy: just type the preferred power level
directly on Smarty keyboard, from 00 to 99. That's all!
For security reason, the truck waits that the throttle is
released before applying the new power level.
No trace is left in the
I herby CLAIM that SmartyCR is the FIRST AND ONLY
downloader that does not erase any of the stored data in
the ECM. Smarty does NOT leave any electronic footprints
in the ECM or any other electronic module in the truck.
Smarty does NOT set ANY codes once the ECM is set back to
stock. Smarty does NOT need to have fuses pulled.
No matter what the competition
claims , in one way or another they're ALL detectable.
Smarty is NOT!
Yet, Smarty can not do one
thing for you. Fix what others have broken. Smarty can not
restore a key on counter that another downloader has
erased. Smarty can not fix VIN# troubles caused by other
products. If your Check engine / ABS light is on because
another product has screwed your ECM, Smarty can not fix
it, the other guy HAS to..
ABS / Speedo recalibration
The tire height can be adjusted up to 44" in increments of
10 tenth of an inch in just a couple seconds. Of course,
Smarty needs to be VIN# locked to the truck in order to
get into the ABS adjustment section.
DTC Code reader
The name says it all.
You can read and erase codes. Codes are displayed also in
plain English. That's old news by now. Smarty S-03 was the
first one to provide that utility, others found the idea
to be a good one too. (Smarty does erase ABS codes too but
does not display them)
ECM update speed
Faster than anything else on the market! Again we've done
our homework on the protocol. Less than 5 minutes. Three
times faster than a Star-Scan diagnostic tool or
We have developed our own
bootloader in order to not have to pull fuses should an
update become interrupted for any reason. All you have to
do is to turn the key off / key on Smarty does everything
else on it's own.
The CaTCHER softwares as they are today are only a
starting point. Expect major news in future. We’re for
your feedback, opinions, likes, dislikes...
We will make Smarty do what
YOU want, TOGETHER.
